outdoor fiber optic fibra optica cable aerial duct direct method Direct Buried Steel Armored 12 96 Core Fiber Optic Cable Gyta53

  • Description
Inquiry

Is there a problem? Please contact us to serve you!

Inquiry

The Qitian outdoor fiber optic fibra optica cable aerial duct direct method Direct Buried Steel Armored 12 96 Center Fiber Optic Cable Gyta53 is a high-grade item is developed towards improve your outdoor web connection expertise. This top-quality item was crafted along with cutting edge Direct Buried Steel Armored 12 96 Center Fiber Optic Cable Gyta53 innovation, that makes it extremely incredibly dependable and resilient.


The Qitian outdoor fiber cable is optic especially developed towards endure the most difficult outdoors environmental problems. Be it environment is severe temperature levels, and even wild animals, this cable is solid sufficient towards endure a wide variety of outdoors tensions. The steel shield furthermore assists towards guarantee the cable is still safeguarded versus genuine invasion as well as problems.


The Qitian fiber optic cable ordinarily a simple job towards steadfastly maintains, complying with its own aerial duct direct method innovation. This will create the cable rather simple towards set up and accessibility, creating this possible for provider towards repair as well as maintain the urban area. Helped through the Qitian outdoor soluble fiber optic cable, there's no require to become worried around disruptions, also right in to the huge occasion of body mistakes.


Likewise, the Qitian outdoor fiber optic cable is created along with resilient fiber optic fibra optica products provide efficiency is high-quality. These products are actually created towards withstand reduction is notify ensuring your link is still solid and steady. The 12 96 center fiber optic cable structure likewise guarantees you have obtained higher data transfer abilities, enabling web connectivity that's smooth.


The Qitian outdoor fiber optic cable is a high-grade item which provides high-performance web connection, whatever the severe outdoor problems. Its own amazing direct method innovation, resilient products, and steel shield guarantee it is a reliable as well as credible product when it concerns outdoors web demands. Obtain your Qitian nutritional is actually outdoors optic cable today and expertise reliable neighborhood connection such as practically no time at all prior to.


Fiber Count
Cable Diameter(mm)
Cable Weight(kg/km)
Tensile Strength(N)
Crush Resistance(N/100mm)
Bending Radius(mm)






Long/Short Term
Long/Short Term
Static/ Dynamic
2~36
10.5
107
600/1500
300/1000
10D/20D



38~72
11.2
125
600/1500
300/1000
10D/20D



74~84
11.9
138
600/1500
300/1000
10D/20D



86~96
12.5
155
600/1500
300/1000
10D/20D



98~108
13.2
172
600/1500
300/1000
10D/20D



132-144
15.3
220
600/1500
300/1000
10D/20D



288
18.3
335
600/1500
300/1000
10D/20D



Features:

(1) Direct burial, underground cable;
(2) 2~432 optical fibers(250um) available;
(3) PE/HDPE/LSZH outer sheath available;
(4) Rodent protected crush resistance;
(5) Provide strong water-resistance performance;
(6) Corrugated tape and dual sheath construction for indoor/outdoor environments;
(7) Provide high crush resistant and tensile performance;
(8) Meet the requirements of IEC 60331-25, IEC 60332, IEC 61034, IEC 60754;
(9) G652.D, G655, G657A1/A2,......OM1,OM2,OM3,OM4 optical fibers available.

Application:

(1) Long distance and local area network communications;
(2) Junction communications system;
(3) Adopted for outdoor backbone cable, distribution cable;
(4) Suitable for Direct burial, Underground, Duct cabling environment.
